Description
PRMDUO is used to control the temperature of heating elements. Depending on the version, the maximum regulated power is 3x5kW (3x230V or 3x400V).
Using the knob, the user can adjust the temperature to which he is aiming and the power supplied to the system. The current temperature and power setting is displayed on the graphic LCD display connected by a cable to the main unit.

The device can control the process of distillation, curing (smoking) or brewing beer

Without probes, it allows you to regulate the power delivered to the heating circuit.
The device can be equipped with a temperature probe (or two) so that it can maintain a constant temperature or limit its maximum value (protection)
A second probe can be connected to the device. The second probe, in addition to measuring the second temperature, allows the device to end. This is particularly useful e.g. when:
- during curing (smoking), the second probe is placed in the meat and the process is to end when the temperature is reached, e.g. "Ta = 80" degrees
- during distillation, the second probe is placed in keg and the process is to end when the temperature in keg exceeds a certain value, e.g. "Ta = 90" degrees

When controlling the brewing process, the user can choose up to 10 time and temperature settings (process steps)
In addition, the user can save up to 5 different process configurations, so you can brew 5 different beers.

Additional output can be used for:

- valve control

- stirrer control

- pump control (Braumeister)

- controlling an additional heater from the second phase (via contactor)

Advantages
Easy assembly
Readable graphic display
Display rotated 180 degrees (down / up)
Set minimum power
Set maximum power
Ease of use

Warranty
60 months

Technical data
Supply voltage: 230V / 50Hz +/- 10%
Power regulation resolution: 0.25% or 1% set by the user
Power adjustment range: 0-100%
Temperature adjustment range: 10-115 degrees
Temperature resolution: 0.025 degrees
Maximum adjustable power value: 3x5kW (3x230V or 3x400V)
Maximum power consumption: 1.5W
Thermal protection: YES
Cooling: forced (built-in fan)

Due to the universality of the probe are not included. Please purchase them separately.
